HIGH HOPE ELECTRONIC & SCIENTIFIC CO.,LTD.

8 INCH WOOFER   MODEL:WF17-8

SIZE：8” INCH WOOFER ALUMINUM BASKET

POWER：RMS 300 /600W WATTS MAX

VOICE COIL：  2.4 ” KSV AL winding 16mm
MAGNET：DIA 156*70*20mm  Y30 50 OZ
T-YOKE :8mm

Washer : 6mm

IMPEDANCE：8 OHMS DC:6.5ohms

FREQ.RESP.：38HZ-8KHZ
SENSITIVITY：87 dB/W/M

10 INCH WOOFER   MODEL:WF17-10

SIZE：10” INCH WOOFER ALUMINUM BASKET

POWER：RMS 300 /600W WATTS MAX

VOICE COIL：  2.4 ” KSV AL winding 16mm
MAGNET：DIA 170*80*25mm  Y30 60 OZ
T-YOKE :8mm

Washer : 8mm

IMPEDANCE：8 OHMS DC:6.5ohms

FREQ.RESP.：36HZ-7KHZ
SENSITIVITY：87 dB/W/M

12 INCH WOOFER   MODEL:WF17-12

SIZE：12” INCH WOOFER ALUMINUM BASKET

POWER：RMS 400 /800W WATTS MAX

VOICE COIL：  3 ” KSV AL winding 16mm
MAGNET：DIA 170*80*25mm  Y30 75 OZ
T-YOKE :8mm

Washer : 8mm

IMPEDANCE：8 OHMS DC:6.5ohms

FREQ.RESP.：35HZ-6.5KHZ
SENSITIVITY：85 dB/W/M

15 INCH WOOFER   MODEL:WF17-15

SIZE：15” INCH WOOFER ALUMINUM BASKET

POWER：RMS 500 /1000W WATTS MAX

VOICE COIL：  4 ” KSV AL winding 16mm
MAGNET：DIA 220*110*25mm  Y30 125 OZ
T-YOKE :8mm

Washer : 8mm

IMPEDANCE：8 OHMS DC:6.5ohms

FREQ.RESP.：32HZ-6KHZ
SENSITIVITY：87 dB/W/M

18 INCH WOOFER   MODEL:WF17-18

SIZE：18” INCH WOOFER ALUMINUM BASKET

POWER：RMS 800 /1600W WATTS MAX

VOICE COIL：  5 ” KSV AL winding 22mm
MAGNET：DIA 253*140*25mm  Y30 207 OZ
T-YOKE :10mm

Washer : 10mm

IMPEDANCE：8 OHMS DC:6.5ohms

FREQ.RESP.：32HZ-6KHZ
SENSITIVITY：86 dB/W/M
