HIGH HOPE ELECTRONIC & SCIENTIFIC CO.,LTD.

8 INCH WOOFER   MODEL:WF195-8

SIZE：8” INCH WOOFER

POWER：RMS 400W /800W WATTS MAX

VOICE COIL： 3 ” KSV  AL winding 14mm
MAGNET：DIA φ156*φ70*20MM Y30 50 OZ
IMPEDANCE：8 OHMS DC:6.5ohms

T-YOKE :6mm

Washer :6mm

FREQ.RESP.：38HZ-8KHZ
SENSITIVITY：92 dB/W/M

10 INCH WOOFER   MODEL:WF195-10

SIZE：10” INCH WOOFER

POWER：RMS 400W /800W WATTS MAX

VOICE COIL：  3 ” KSV AL winding 16mm
MAGNET：DIA 170*85*25mm  Y30 60 OZ
T-YOKE :8mm

Washer : 8mm

IMPEDANCE：8 OHMS DC:6.5ohms

FREQ.RESP.：36HZ-7.5KHZ
SENSITIVITY：93 dB/W/M

12 INCH WOOFER   MODEL:WF195-12

SIZE：12” INCH WOOFER

POWER：RMS 500W /1000W WATTS MAX

VOICE COIL：  4 ” KSV AL winding 18mm
MAGNET：DIA 220*110*20mm  Y30 100 OZ
T-YOKE :8mm

Washer : 8mm

IMPEDANCE：8 OHMS DC:6.5ohms

FREQ.RESP.：35HZ-7KHZ
SENSITIVITY：92 dB/W/M

15 INCH WOOFER   MODEL:WF195-15

SIZE：15” INCH WOOFER

POWER：RMS 800W /1600W WATTS MAX

VOICE COIL：  4 ” KSV AL winding 22mm
MAGNET：DIA 220*110*25mm  Y30 125 OZ
T-YOKE :8mm

Washer : 8mm

IMPEDANCE：8 OHMS DC:6.5ohms

FREQ.RESP.：32HZ-6.5KHZ
SENSITIVITY：90 dB/W/M
